ADR Touch SOLO 3000 BS EN Compression Machine with Digital Readout and Self Centring Platens.

Weight 900 kg Dimensions 145 × 62 × 160 cm Brand Nl Test Model number NL 4000 X / 034N Max Vertical Clearance (mm) 382 mm Max Horizontal Clearance (mm) 270 mm Capacity 2000kN Platen Sizes (mm) 295 mm Piston Ram Diameter 250 mm Max Ram Travel (mm) 60 mm Column Diameter Ø70 mm Voltage Supply 220 – 240 V AC, 50 – 60 Hz, 1 ph Accuracy Class 1 Relative Error ±1% Repeatability Relative Error 1% Resolution 0.1 – 0.001 kN Sensor Accuracy 0.1% Max. Hydraulic Working Pressure 50 Mpa
